HKM 65 V

Description

Standard Equipments	PUNCHING	HKM 65 V
	Diameter x max. thickness	Ø 22×20 mm
	Diameter x thickness	–
	Maximum Diameter	Ø 38×11 mm
	Stroke	40 mm
	Stroke count in (20 mm)	(15mm) x 22
	Throat depth	240 mm
	Working height	1050 mm
Standard Equipments	STEEL BAR SHEAR	HKM 65 V
Standard Equipments	Round / Square	Ø 40- 38 mm
Standard Equipments	ANGLE SHEAR	HKM 65 V
	Angle section (90°)	100x100x10 mm
	Angle section (45°)	–
	Working height	1070 mm
Standard Equipments	SHEET METAL SHEAR	HKM 65 V
	Sheet metal	350×15 mm
	Sheet metal	–
	Blade Length	352 mm
	Shearing with angle	70×7 mm
	Working height	810 mm
Standard Equipments	NOTCHING	HKM 65 V
	Thickness	8 mm
	Width	50.8 mm
	Depth	90 mm
	Working height	1060 mm
Optional Equipments	OPTIONAL TOOLS	HKM 65 V
	U-I Section blades (for UPN – IPN cutting)	100×50 mm
		–
Optional Equipments	Special V-Notching tooling	90x90x8 mm
Optional Equipments	V – bending Press Brake Bar bend Max.	160×8 mm
Optional Equipments	V – bending Press Brake Sheet bend. max.	250×6 mm
Optional Equipments	Punching on notcher Throat depth	–
Optional Equipments	Punching on notcher Max. capacity	–
	TECHNICAL DATA	HKM 65 V
	Motor Power	5. 5 kW
	Weight	1215 kg
	Machine Dimensions (LxWxH)	1180x900x1920 mm
	Power (Pressure)	65 ton
