Z series

Description

SZ 32 series
Drill of round column manual feed
Feed manual
Transmission v-belt
Column diameter: 125 mm
Distance from spindle to column: 300 mm
Fixed moveable table
Drilling capacity: ⌀ 32 mm
Tapping capacity: M 22
Spindle cone: CM 3
Engine power: 1.2/1.8 HP
Num. and selections of speeds: (10) 145-1720 rpm
Drilling depth: 150 mm
Weight: 260 kg
Measurements: 2,30 x 0,6 x 1,1 m.

AZ 32V series
Drill of round column mechanical automatic feed
Feed mechanical automatic
Feed: (2) 0.10-0.2
Transmission mechanical variator belts
Column diameter: 125 mm
Distance from spindle to column: 300 mm
Fixed moveable table
Drilling capacity: ⌀ 32 mm
Tapping capacity: M 22
Spindle cone: CM 3
Engine power: 1.2/1.8 HP
Speeds: Continuous: (80-1170) rpm
Drilling depth: 150 mm
Weight: 290 kg
Measurements: 2,30 x 0,6 x 1,1 m.

SZ 34 series
Drill of round column manual feed
Feed manual
Transmission electronic variator belt
Column diameter: 125 mm
Distance from spindle to column: 300 mm
Fixed moveable table
Drilling capacity: ⌀ 34 mm
Tapping capacity: M 27
Spindle cone: CM 4
Engine power: 4 HP
Speeds: Continuous: (100-2000) rpm
Drilling depth: 150 mm
Weight: 345 kg
Measurements: 2,30 x 0,6 x 1,1 m.

SZ 40 series
Drill of round column manual feed
Feed manual
Transmission electronic variator belt
Column diameter: 150 mm
Distance from spindle to column: 350 mm
Tiltable rotating table
Drilling capacity: ⌀ 40 mm
Tapping capacity: M 33
Spindle cone: CM 4
Engine power: 5.5 HP
Speeds: Continuous: (100-2000) rpm
Drilling depth: 180 mm
Weight: 445 kg
Measurements: 2,30 x 0,6 x 1,1 m.

AZ 34 series
Drill of round column mechanical automatic feed
Feed mechanical automatic
Feed: (3) 0.10-0.2-0.3
Transmission electronic variator belt
Column diameter: 125 mm
Distance from spindle to column: 300 mm
Fixed table
Drilling capacity: ⌀ 34 mm
Tapping capacity: M 27
Spindle cone: CM 4
Engine power: 4 HP
Speeds: Continuous: (100-2000) rpm
Drilling depth: 150 mm
Weight: 360 kg
Measurements: 2,30 x 0,6 x 1,1 m.

AZ 40 series
Drill of round column mechanical automatic feed
Feed mechanical automatic
Feed: (3) 0.10-0.2-0.3
Transmission electronic variator belt
Column diameter: 150 mm
Distance from spindle to column: 350 mm
Tiltable rotating table
Drilling capacity: ⌀ 40 mm
Tapping capacity: M 33
Spindle cone: CM 4
Engine power: 5.5 HP
Speeds: Continuous: (100-2000) rpm
Drilling depth: 180 mm
Weight: 460 kg
Measurements: 2,30 x 0,6 x 1,1 m.

BZ 34 series
Drill of round column electromagnetic automatic feed
Feed electromagnetic automatic
Feed: (3) 0.10-0.2-0.3
Transmission electronic variator belt
Column diameter: 125 mm
Distance from spindle to column: 300 mm
Fixed moveable table
Drilling capacity: ⌀ 34 mm
Tapping capacity: M 27
Spindle cone: CM 4
Engine power: 4 HP
Speeds: Continuous: (100-2000) rpm
Drilling depth: 150 mm
Weight: 370 kg
Measurements: 2,30 x 0,6 x 1,1 m.

BZ 40 series
Drill of round column electromagnetic automatic feed
Feed electromagnetic automatic
Feed: (3) 0.10-0.2-0.3
Transmission electronic variator belt
Column diameter: 150 mm
Distance from spindle to column: 350 mm
Tiltable rotating table
Drilling capacity: ⌀ 40 mm
Tapping capacity: M 33
Spindle cone: CM 4
Engine power: 5.5 HP
Speeds: Continuous: (100-2000) rpm
Drilling depth: 180 mm
Weight: 470 kg
Measurements: 2,30 x 0,6 x 1,1 m.
